Gigabyte B860M D3HP

Model:

Gigabyte B860M D3HP

CPU Support:

Intel® Core™ Ultra Processors (LGA1851 Socket)

Chipset:

Intel® B860 Express Chipset

DIMM Slots:

4 x DDR5 DIMM Slots

Max Memory support:

Up to 256GB (64GB per DIMM)

PCI-E Slots:

1 x PCIe 5.0 x16, 2 x PCIe 3.0 x1

M.2 Slots:

2 x M.2 (PCIe 4.0 x4/x2)

SATA III:

4 x SATA 6Gb/s

ARGB Headers:

2 x Addressable RGB Gen2 Headers

RGB Headers:

1 x RGB LED Header

Fan Headers:

4 (CPU Fan, CPU/WP, SYS Fan, SYS/WP)

Front Type C Headers:

1 x USB Type-C (USB 3.2 Gen 1)

Front USB 3 Headers:

1 x USB 3.2 Gen 1 Header

USB 2.0 Headers:

2 x USB 2.0 Headers

Clear COMS Buttons:

1 x Clear CMOS Jumper

Onboard Graphics Outputs:

1 x HDMI 2.1, 1 x DisplayPort 2.1

PS/2 Combo Ports:

1 x PS/2 Keyboard/Mouse Combo Port

USB Ports:

3 x USB 3.2 Gen 1, 3 x USB 2.0 (Rear)

USB Type C Ports:

1 x USB Type-C (via internal header)

Ethernet LAN Port:

Realtek® GbE LAN (1 Gbps)

Bluetoooht & Wireless:

3 x Audio Jacks (Realtek® Audio CODEC, 7.1-channel support)

Operating System:

Windows 11 64-bit, Windows 10 64-bit

Form Factor:

Micro ATX (24.4cm x 24.4cm)
