COOLER MASTER VANGUARD 850W | 2600 EGP

COOLER MASTER VANGUARD 850W

2600 LE
shipped by (sigma)
Point: 0

Seller : sigma

Viewed : 2858 items

V850
Fully modular cable design incorporates a single 1000W +12V output that delivers up to 70A.
80 PLUS Gold certified: up to 93% efficiency @ 50% load
Silent 135 mm FDB fan for lower noise and longer lifespan
Six PCI-E 6+2 pin connectors to support high-end GPUs
100% high quality Japanese capacitor ensures performance and reliability.
Reliable 5 year warranty


MODULAR
Full Modular
MODEL
RS-850-AFBA-G1
PFC
Active PFC (>0.9 typical)
ATX VERSION
Intel Form Factor ATX 12V V2.31
DIMENSIONS (L X W X H)
150 x 170 x 86 mm / 5.9 x 6.7 x 3.4 inch
INPUT VOLTAGE
90-264Vac (Auto Range)
INPUT CURRENT
10-5A
INPUT FREQUENCY
60-50Hz
POWER GOOD SIGNAL
100-500ms
HOLD UP TIME
>17ms
EFFICIENCY
90% Typically
MTBF
>100,000 Hours
PROTECTIONS
OVP, UVP, OPP, OTP, SCP
OUTPUT CAPACITY
850W
OPERATING TEMPERATURE
0-40°C
REGULATORY
CE, TUV, TUV-SUDNRTL, FCC, GOST, CCC, BSMI, C-tick, KCC
FAN SIZE
Silent FDB 135mm
CERTIFICATION
80 Plus Gold
MB 20+4 PIN CONNECTORS
1
CPU 12V 4+4 PIN CONNECTORS
2
PCI-E 6+2 PIN CONNECTORS
6
SATA CONNECTORS
9
PERIPHERAL 4-PIN CONNECTORS
4
FDD CABLE 4-PIN CONNECTORS
1
PRODUCT NAME
V850
WATTAGE
Above 750W
80 PLUS
Gold
SERIE
V Gold Series

CategoryDesktop
SubcategoryPower Supply
BrandCOOLER MASTER
ModelCOOLER MASTER VANGUARD 850W
POWER OF SUPPLY POWER850W
EFFICIENCY RATING80+ Gold
MODULARNon
