Display
Panel Size: Wide Screen 23.8"(60.5cm) 16:9
Panel Type : IPS
True Resolution : 1920x1080
Display Viewing Area(HxV) : 527.04 x 296.46 mm
Display Surface : Non-glare
Pixel Pitch : 0.2745 mm
Brightness(Max) : 250 cd/㎡
Contrast Ratio (Max) : 1000:1
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
Viewing Angle (CR≧10) : 178°(H)/178°(V)
Response Time : 5ms (Gray to Gray)
Display Colors : 16.7M
Flicker free : Yes
Refresh Rate(max) : 75Hz
Video Feature
Trace Free Technology : Yes
SPLENDID Video Preset Modes : 8 Modes (sRGB Mode/Scenery Mode/Theater Mode/Standard Mode/Night View Mode/Game Mode/Reading Mode/Darkroom Mode)
Skin-Tone Selection : 3 Modes
Color Temperature Selection : 4 Modes
QuickFit (modes) : Yes (Alignment Grid/Paper/Photo Modes)
GamePlus(modes) : Yes (Crosshair/Timer/FPS Counter/Display Alignment)
Low Blue Light : Yes
HDCP support : Yes
VividPixel : Yes
FreeSync™ technology supported
Adaptive-Sync supported :Yes
I/O Ports
Signal Input : HDMI, D-Sub, DVI-D
Signal Frequency
Analog Signal Frequency : 24 ~84 KHz (H) /48 ~60 Hz(V)
Digital Signal Frequency : 24 ~84 KHz (H) /48 ~75 Hz(V)
Power Consumption
Power on (Typical) : <13.2W *
Power Saving Mode : < 0.5W
Power Off Mode : <0.5W
Voltage : 100-240V, 50 / 60Hz
Mechanical Design
Chassis Colors : Black
Tilt : -5°~+23°
VESA Wall Mounting : 100x100mm
Frameless Design : Yes
Security
Kensington lock
Dimensions
Phys. Dimension with Stand (WxHxD) : 540.45 x 403.67 x 203.94 mm
Phys. Dimension without Stand (WxHxD) : 540.4 x 324.8 x 44.4 mm
Box Dimension (WxHxD) : 559 x 415 x 127 mm
Weight
Net Weight (Esti.) : 3.57 kg
Net Weight without Stand (For VESA Wall Mount) (Esti.) : 3.18 kg
Gross Weight (Esti.) : 5.5 kg
Accessories
DVI cable (Optional)
VGA cable(Optional)
Power cord
Quick start guide
HDMI cable (Optional)
Warranty Card
Compliance and Standards
BSMI, CB, CCC, CE, CEL level 0, CU, Energy Star 8.0, FCC, ISO-9241-307, KCC, RoHS, TCO8.0, TUV-GS, UkrSEPRO, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, RCM, UL, TUV Flicker-free , eStandby, TUV Low Blue Light, ICES-3, CEC
Note
* Adaptive-Sync/FreeSync™ only can be activated within “48Hz ~ 75Hz” via HDMI port
Category | Monitors |
Brand | ASUS |
Model | VA24EHE |
Display Resolution | Full HD, FHD - 1920 x 1080 |
Screen size | 24 Inch |
panel type | IPS (In-Plane Switching) |
Response Time | 5ms(GTG) |
| 3 years |
Refresh Rate | 75Hz |
FLAT / CURVED | FLAT |
| Yes |
| Yes |
Flicker-free | Yes |
Signal Input | VGA\DVI-D\HDMI |
SYNC TECHNOLOGY | Freesync |
| Yes |
speaker | NO |
Audio | NO |
Touch Screen | NO |
