Sapphire Radeon PULSE RX 5600 XT 6GB GDDR6 OC | 7000 EGP

Sapphire Radeon PULSE RX 5600 XT 6GB GDDR6 OC

7000 LE
shipped by (sigma)
Point: 100

Brand : Sapphire brand

Model : RX 5600 XT

Seller : sigma

Viewed : 2990 items

GPU: Boost Clock: Up to 1750 MHz
Memory:   6GB/192 bit GDDR6. 14 Gbps Effective
Stream Processors:2304
4K@60Hz
Dual-X Cooling Technology

GPU
Radeon™ RX 5600 Graphics
2nd Gen 7nm GPU
RDNA Architecture
Engine Clock
Boost Clock: Up to 1750 MHz
Game Clock: Up to 1615 MHz
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.

Stream Processors
2304
Memory Size/Bus
6GB/192 bit GDDR6
Memory Clock
14 Gbps Effective
Displays
Maximum 4 Displays
Resolution
HDMI™: 4096×2160@60Hz
DisplayPort1.4: 5120×2880@60Hz
Interface
PCI-Express 4.0

Output
1x HDMI
3x DisplayPort


BIOS Support
Dual UEFI
API
Vulkan®
OpenGL® 4.6
OpenCL 2.0
DirectX® 12
Shader Model 6.4
Game Index
Extreme 1080P, 1440P Entry

Sapphire Features
Power Design
Free Flow
TriXX Supported
TriXX Boost
Red LED Logo
Intelligent Fan Control
Precision Fan Control
Robust VRM Cooling
Robust Memory Cooling
Dual-X Cooling Technology
Tough Metal Backplate
PCB Layers
Two-Ball Bearing
Fan Quick Connect
Fuse Protection
Dual BIOS
AMD Features
RDNA Architecture
2nd Gen 7nm GPU
GDDR6 Memory
Power Efficiency
PCI Express 4.0 Support
Video Streaming up to 8K
Display Port 1.4 (HBR3) / DSC
Radeon™ Software
Radeon™ Boost
Radeon™ Image Sharpening
Radeon™ Anti-Lag
AMD FidelityFx
Async Compute
Radeon™ Rays Audio + True Audio Next
Radeon™ FreeSync™ 2 HDR

Cooling
Dual-X Cooling
Dual Fan
Two-Ball Bearing
Form Factor
2.3 slot, ATX
Dimension: 254 x 135 x 46.5(mm)
Power Consumption
160W
OS
Linux®, Windows®  10, Windows®  7 64bit operating system required

System Requirement
Recommended 500 Watt Power Supply (Minimum 450 Watt Power Supply).
1 x 8-pin Power Connector.
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 4GB of system memory. 8GB recommended.

CategoryDesktop
SubcategoryGraphic Card
BrandSapphire
Model RX 5600 XT
Graphic CardAMD Graphic RX
GPU memory size(GB)6GB
dram type (DDR)DDR6
