Display
Panel Size (inch) : 23.8
Panel Size (inch):23.8
Aspect Ratio : 16:9
Curvature:Not curved panel
Display Viewing Area (H x V) : 527.04 x 296.46 mm
Aspect Ratio16:9
Display Surface : Non-Glare
Color Space (sRGB) :100%
Backlight Type : LED
Panel Type:IPS
Panel Type : IPS
Panel Backlight:LED
Viewing Angle (CR≧10, H/V) : 178°/ 178°
True Resolution:1920x1080
Curvature : Not curved panel
Display Viewing Area(HxV):527.04 x 296.46 mm
Pixel Pitch : 0.2745mm
Display Surface:Non-Glare
Resolution : 1920x1080
Pixel Pitch:0.2745mm
Color Space (sRGB) : 100%
Brightness (Typ.):250cd/㎡
Brightness (Typ.) : 250cd/㎡
Contrast Ratio:1000:1
Contrast Ratio (Typ.) : 1000:1
Viewing Angle (CR≧10):178°/ 178°
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
Response Time:1ms MPRT
Display Colors : 16.7M
Display Colors:16.7M
Response Time : 1ms MPRT
Flicker free:Yes
Refresh Rate (Max) : 75Hz
Refresh Rate(max):75Hz
Flicker-free : Yes
Video Feature
Trace Free Technology : Yes
Trace Free Technology:Yes
SPLENDID Technology : Yes
GamePlus:Yes
Low Blue Light:Yes
Color Temp. Selection : Yes(4 modes)
HDCP Support:Yes
VRR Technology:FreeSync
GamePlus : Yes
QuickFit : Yes
HDCP : Yes
Extreme Low Motion Blur : Yes
VRR Technology : FreeSync
Low Blue Light : Yes
I/O Ports
HDMI(v1.4)x 1
D-Subx 1
HDMI(v1.4) x 1
VGA x 1
Signal Frequency
Digital Signal Frequency : 30~83 KHz (H) / 48~75 Hz (V)
Digital Signal Frequency:30~83 KHz (H) / 48~75 Hz (V)
Analog Signal Frequency : 30~83 KHz (H) / 48~75 Hz (V)
Analog Signal Frequency :30~83 KHz (H) / 48~75 Hz (V)
Power Consumption
Power Consumption : <18W*
Power Consumption:<18W*
Power Off Mode : <0.3W
Power Saving Mode:<0.5W
Power Saving Mode : <0.5W
Power Off Mode:<0.3W
Voltage : 100-240V, 50/60Hz
Voltage:100-240V, 50/60Hz
Mechanical Design
Tilt : Yes (+22° ~ -5°)
Tilt:Yes (+22° ~ -5°)
VESA Wall Mounting:75x75mm
VESA Wall Mounting : 75x75mm
Kensington Lock:Yes
Kensington Lock : Yes
Dimensions
Phys. Dimension with Stand (W x H x D) : 539.5 x 406.5 x 213 mm
Phys. Dimension with Stand(WxHxD):539.5 x 406.5 x 213 mm
Phys. Dimension without Stand (W x H x D) : 539.5 x 319.5 x 36.5 mm
Phys. Dimension without Stand (WxHxD):539.5 x 319.5 x 36.5 mm
Box Dimension (W x H x D) : 595 x 158 x 475 mm
Box Dimension (WxHxD):595 x 158 x 475 mm
Weight
Net Weight with Stand : 3.0 Kg
Net Weight with Stand:3.0 Kg
Net Weight without Stand : 2.5 Kg
Net Weight without Stand:2.5 Kg
Gross Weight : 5.0 Kg
Gross Weight:5.0 Kg
Accessories (vary by regions)
HDMI cable
Power adapter
Power cord
Quick start guide
Warranty Card
Operation Temperature / Humidity
Operation temperature : 0~+40°C
Compliance and Standards
TÜV Flicker-free
TÜV Low Blue Light
Category | Monitors |
Brand | ASUS |
Model | VZ249HEG1R |
Display Resolution | Full HD, FHD - 1920 x 1080 |
Screen size | 24 Inch |
panel type | IPS (In-Plane Switching) |
Response Time | 1ms (MPRT) |
| 3 years |
Refresh Rate | 75Hz |
FLAT / CURVED | FLAT |
| Yes |
| Yes |
Flicker-free | Yes |
Signal Input | HDMI / VGA |
SYNC TECHNOLOGY | Freesync |
| NO |
speaker | NO |
Audio | NO |
Touch Screen | NO |
