COOLER MASTER MWE 550 BRONZE - V2 230V 550W | 1320 EGP

COOLER MASTER MWE 550 BRONZE - V2 230V 550W

1320 LE
shipped by (sigma)
Point: 10

Seller : sigma

Viewed : 3843 items

DC-to-DC + LLC Circuit Design
High Temperature Resistance
Peak Power Tolerance
80 PLUS Bronze 230V EU Certified
Durable, Reliable, and Safe


MODEL
MPE-5501-ACABW-B
ATX VERSION
ATX 12V V2.52
PFC
Active PFC
INPUT VOLTAGE
200-240Vac
INPUT CURRENT
10-5A
INPUT FREQUENCY
50-60Hz
DIMENSIONS (L X W X H)
140 x 150 x 86 mm
FAN SIZE
120mm
FAN BEARING
HDB
FAN SPEED
1500 RPM
NOISE LEVEL @ 20%
13.8 dBA
NOISE LEVEL @ 50%
18.4 dBA
NOISE LEVEL @ 100%
31.2 dBA
EFFICIENCY
88% Typically
80 PLUS RATING
80 PLUS Bronze EU 230V
ERP 2014 LOT 3
Yes
POWER GOOD SIGNAL
100 - 500 ms
HOLD UP TIME
>18ms at 100% Full Load@230Vac
MTBF
>100,000 Hours
PROTECTIONS
OVP, OPP, SCP, UVP, OTP
REGULATORY
CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
ATX 24-PIN CONNECTORS
1
EPS 4+4 PIN CONNECTORS
1
SATA CONNECTORS
6
PERIPHERAL 4-PIN CONNECTORS
3
PCI-E 6+2 PIN CONNECTORS
2
SERIES
MWE Bronze Series
80 PLUS
Bronze
MODULAR
Non Modular
WATTAGE
500 to 750W

CategoryDesktop
SubcategoryPower Supply
BrandCOOLER MASTER
ModelMPE-5501-ACABW-BWO
POWER OF SUPPLY POWER550W
EFFICIENCY RATING 80+ Bronze
MODULARNon
