MODEL
MPE-6501-ACABW-B
ATX VERSION
ATX 12V V2.52
PFC
Active PFC
INPUT VOLTAGE
200-240Vac
INPUT CURRENT
10-5A
INPUT FREQUENCY
50-60Hz
DIMENSIONS (L X W X H)
140 x 150 x 86 mm
FAN SIZE
120mm
FAN BEARING
HDB
FAN SPEED
2400 RPM
NOISE LEVEL @ 20%
16.54 dBA
NOISE LEVEL @ 50%
26.5 dBA
NOISE LEVEL @ 100%
42.5 dBA
EFFICIENCY
88% Typically
80 PLUS RATING
80 PLUS Bronze EU 230V
ERP 2014 LOT 3
Yes
POWER GOOD SIGNAL
100 - 500 ms
HOLD UP TIME
>18ms at 100% Full Load@230Vac
MTBF
>100,000 Hours
PROTECTIONS
OVP, OPP, SCP, UVP, OTP
REGULATORY
CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
ATX 24-PIN CONNECTORS
1
EPS 4+4 PIN CONNECTORS
1
EPS 8 PIN CONNECTOR
1
SATA CONNECTORS
6
PERIPHERAL 4-PIN CONNECTORS
3
PCI-E 6+2 PIN CONNECTORS
4
SERIES
MWE Bronze Series
80 PLUS
Bronze
MODULAR
Non Modular
WATTAGE
500 to 750W
Document
Product Sheet
Cable Type EAN UPC
BUS 4719512104378 884102076688
BUK 4719512104385 884102076695
BEU 4719512104392 884102076701
BST 4719512104408 884102076718
BAU 4719512104415 884102076725
BBR 4719512104422 884102076732
BKR 4719512104439 884102076749
BTW 4719512104446 884102076756
JP 4719512104453 884102076763
BIN 4719512104460 884102076770
BWO 4719512104477 884102076787
Category | Desktop |
Subcategory | Power Supply |
Brand | COOLER MASTER |
Model | MPE-6501-ACABW-BEU |
POWER OF SUPPLY POWER | 650W |
EFFICIENCY RATING | 80+ Bronze |
MODULAR | Non |
