Cougar GEX 750W 80+ Gold Certified Power Supply | 1900 EGP

Cougar GEX 750W 80 Gold Certified Power Supply

1900 LE
shipped by (sigma)
Point: 50

Brand : COUGAR brand

Model : GEX750

Seller : sigma

Viewed : 3599 items

80 PLUS Gold Certified
Up to 91% efficiency power conversion to cut down your electricity bill

Fully Modular Power Supply Unit
Connect only the cables you need for less clutter and better airflow

COUGAR HDB Fan
Hydro Dynamic Bearing Fan: Extended durability and lower noise levels

Superior fan Curve Tuning
Advanced technology for noise minimization

Flawless Operation at 40°C
Powerful performance at 40°C ambient temperature

Ultra-stable Voltage Outputs
DC to DC technology for enhanced voltage stability

Strong Safeguards : OCP, OPP, OVP, UVP, SCP & OTP
Maximum safety for your key system components


Brand COUGAR
Series GEX Series
Model GEX750
Details
Type ATX12V
Maximum Power 750 W
Fans 120mm Hydro Dynamic Bearing Fan
Main Connector 20+4Pin
+12V Rails Single
PCI-Express Connector 4 x 6+2-Pin
SATA Power Connector 8
Modular Full Modular
Efficiency Up to 91% efficiency
Energy-Efficient 80 PLUS GOLD Certified
Protection OCP, OPP, OVP, UVP, SCP & OTP
Input Voltage 100 - 240 V
Input Frequency Range 50/60 Hz
Input Current 10 - 5 A
Output +3.3V@18A, +5V@20A, [email protected], [email protected], +5Vsb@3A
MTBF >100,000 Hours
Max PSU Length 160 mm
Connectors 1 x Main 24(20+4) Pins
2 x CPU 8(4+4) Pins
4 x PCI-E 8(6+2) Pins
8 x S-ATA 5 Pins
6 x Peripherals 4 Pins

CategoryDesktop
SubcategoryPower Supply
BrandCOUGAR
ModelGEX750
POWER OF SUPPLY POWER750W
EFFICIENCY RATING80+ Gold
MODULARNon
