EVGA 850 B5, 80 Plus BRONZE 850W, Fully Modular, EVGA ECO Mode Compact 150mm Size, Power Supply 220-B5-0850-V2 | 2850 EGP

EVGA 850 B5 80 Plus BRONZE 850W Fully Modular EVGA ECO Mode Compact 150mm Size Power Supply 220-B5-0850-V2

2850 LE
shipped by (sigma)
Point: 50

Brand : EVGA brand

Seller : sigma

Viewed : 3885 items

80 PLUS Bronze certified, with 85% efficiency or higher under typical loads
Fully Modular to reduce clutter and improve airflow
EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)


ATX Cable 1x 600mm (m)
EPS Cable 2x 600mm (m)
PCIE Cable 3x 550mm, 700mm (m)
SATA Cable 3x 500mm, 600mm, 700mm(m)
Four-Pin Peripheral Cable 1x 500mm, 600mm, 700mm(m)
Flexible Adapter 1x Molex to FDD Adapter
AC Power 1x 1500mm (m)
Modular Cable Type Full
Molex to FDD 1x
NUMBER OF CONNECTORS
24 ATX Pin 1x 24pin (20+4)
EPS (CPU) 2x 8pin (4+4)
PCIE 6x 8pin (6+2)
SATA 9x
Four-Pin Peripheral 3x
Floppy 1x
POWER SPECIFICATIONS
AC Entrance 100-240V~, 10-5A, 60/50Hz
DC Output +3.3V +5V +12V +5Vsb -12V
MAX Output 24A 24A 70.8A 3.0A 0.5A
850W
120W 850W 254 6W
Output Power 850W
ADDITIONAL DETAILS
Operating Temperature 0° to 50° C
Japanese Capacitors 100%
ECO Mode Yes
MTBF 100,000 Hours
Net weight 5 lbs
Size 86mm (H) x 150mm (W) x 150mm (L)
Approvals TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 3 2014 Requirement
Fan/Bearing Size 135mm Fluid Dynamic Bearing
CategoryDesktop
SubcategoryPower Supply
BrandEVGA
Model220-B5-0850-V2
POWER OF SUPPLY POWER850W
EFFICIENCY RATING 80+ Bronze
MODULARFull
