XPG Pylon Power Supply - 750 Watt 80 Plus Bronze Certified | 3150 EGP

XPG Pylon Power Supply - 750 Watt 80 Plus Bronze Certified

3150 LE
shipped by (sigma)
Point: 50

Brand : XPG brand

Model : Pylon 750Wat

Seller : sigma

Viewed : 5673 items

DC to DC Converters
80PLUS BRONZE Certified
Continuous Power for 24/7 system operation
120mm FDB Silent-Performance Fan
High Current +12V rail system compatibility
Main Japanese Capacitor
Multiple PCI-E 2.0 6+2 Pin Connectors
Industrial-Level Protection OVP, OPP, SCP, OCP, UVP, OTP, NLO, SIP
Complies with ErP 2014 Lot 3
RoHS Compliance












Dimensions (L x W x H)
150 x 140 x 86mm

80 PLUS RATING
BRONZE

ATX Version
Intel ATX 12V V2.4 (Timing complies with Intel ATX12V Specific guidelines to version 2.52)

Protections
OCP / OVP / UVP / OPP / SCP / OTP / NLO / SIP

Certification
CE / UKCA / CB / FCC (IC) / EAC / CCC / TUV / cTUVus / TUV S-Mark / RCM / NOM / BSMI / KC

PFC
0.99

Input Voltage
100-240V

Input Current
750W:10A/5A 、650W:10A/5A 、550W:8A/4A 、450W:7A/3.5A

Input Frequency
50Hz - 60Hz

Operating Temperature
50℃

Fan Size
120mm

Fan Bearing
FDB (Fluid Dynamic Bearing)

Fan Speed
2,000 RPM

Noise Level

MTBF
100K Hours at 25℃

ATX 24 Pin Connector
1

EPS 8 (4+4) Pin Connector
750W : 1 / 650W : 1 / 550W : 1 / 450W:1

PCI-E 6+2 Pin Connector
750W : 4 / 650W : 4 / 550W : 2 / 450W:2

SATA Connector
750W : 8 / 650W : 8 / 550W : 5 / 450W:5

Peripheral 4 Pin Connector
750W : 1 / 650W : 1 / 550W : 1 / 450W:1

Floppy 4 Pin Connector

Weight
750W:
Product:2.12kg (4.7lb) ±5%
with Package:2.63kg (5.8lb) ±5%
650W:
Product:1.87kg (4.1lb) ±5%
with Package:2.38kg (5.2lb) ±5%
550W:
Product:1.77kg (3.9lb) ±5%
with Package:28kg (5.0lb) ±5%
450W:
Product:1.67kg (3.7lb) ±5%
with Package:2.2kg (4.9lb) ±5%







CategoryDesktop
SubcategoryPower Supply
BrandXPG
ModelPylon 750Wat
POWER OF SUPPLY POWER750W
EFFICIENCY RATING 80+ Bronze
MODULARNon
