Display
Display Size (in.): 22
Viewable Area (in.): 21.5
Panel Type: VA Technology
Resolution: 1920 x 1080
Resolution Type: FHD
Static Contrast Ratio: 3,000:1 (typ)
Dynamic Contrast Ratio: 50M:1
Light Source: LED
Brightness: 250 cd/m² (typ)
Colors: 16.7M
Color Space Support: 8 bit true
Aspect Ratio: 16:9
Response Time (Typical GTG): 4ms
Viewing Angles: 178º horizontal, 178º vertical
Backlight Life (Hours): 30000 Hrs (Min)
Curvature: Flat
Refresh Rate (Hz): 75
Adaptive Sync: Yes
Blue Light Filter: Yes
Flicker-Free: Yes
Color Gamut: NTSC: 72% size (Typ), sRGB: 100% size (Typ)
Pixel Size: 0.249 mm (H) x 0.241 mm (V)
Surface Treatment: Anti-Glare, Hard Coating (3H)
Compatibility
PC Resolution (max): 1920x1080
Mac® Resolution (max): 1920x1080
PC Operating System: Windows 10 certified; macOS tested
Mac® Resolution (min): 1920x1080
Connector
VGA: 1
HDMI 1.4: 1
Power in: 3-pin Socket (IEC C14 / CEE22)
Power
Eco Mode (Conserve): 15W
Eco Mode (optimized): 18W
Consumption (typical): 22W
Consumption (max): 24W
Voltage: AC 100-240V, 50/60 Hz
Stand-by: 0.5W
Power Supply: Internal
Additional Hardware
Kensington Lock Slot: 1
Controls
Physical Controls: Key 1 (favorite), Key 2, Key 3 (power), Key 4, Key 5
On Screen Display: Input Select, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu
Operating Conditions
Temperature: 32°F to 104°F (0°C to 40°C)
Humidity (non-condensing): 20% to 90%
Wall Mount
VESA Compatible: 100 x 100 mm
Input Signal
Frequency Horizontal: 24 ~ 86KHz
Frequency Vertical: 48 ~ 75Hz
Video Input
Digital Sync: TMDS - HDMI (v1.4)
Analog Sync: Separate - RGB Analog
Ergonomics
Tilt (Forward/Back): -3º / 20º
Weight (imperial)
Net (lbs): 5.3
Gross (lbs): 7.7
Weight (metric)
Net (kg): 2.4
Gross (kg): 3.5
Dimensions (imperial) (wxhxd)
Packaging (in.): 21.9 x 13.8 x 4.7
Physical (in.): 19.4 x 14.4 x 6.5
Physical Without Stand (in.): 19.4 x 11.3 x 1.6
Dimensions (metric) (wxhxd)
Packaging (mm): 555 x 350 x 120
Physical (mm): 492 x 367 x 165
Physical Without Stand (mm): 492 x 288 x 40
General
Regulations: CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO
PACKAGE CONTENTS: VA2201-H x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v1.4; Male-Male) x1, Quick Start Guide x1
Category | Monitors |
Brand | VIEWSONIC |
Model | VA2201-H |
Display Resolution | Full HD, FHD - 1920 x 1080 |
Screen size | 22 Inch |
panel type | VA (Vertical Alignment) |
Response Time | 4 ms GTG |
Refresh Rate | 75Hz |
FLAT / CURVED | FLAT |
Flicker-free | Yes |
Signal Input | HDMI / VGA |
SYNC TECHNOLOGY | Not Supported |
speaker | Yes |
Audio | YES |
Touch Screen | NO |
