Cooler Master HAF500 White Edition: ATX Mid-Tower with tempered glass, dual 200mm ARGB fans, USB 3.2 Gen 2 Type-C, rotatable GPU fan, support for up to E-ATX motherboards and dual 360mm radiators | 6299 EGP

Cooler Master HAF500 White Edition ATX Mid-Tower with tempered glass dual 200mm ARGB fans USB 3.2 Gen 2 Type-C rotatable GPU fan support for up to E-ATX motherboards and dual 360mm radiators

6299 LE
Availability: In Stock
shipped by (sigma)
Point: 50

Model : HAF500

Seller : sigma

Viewed : 6572 items

Cooler Master HAF500 White Edition - Key Specifications

  • Case Type: ATX Mid-Tower

  • Material: Steel, Mesh, Tempered Glass

  • Dimensions: 516 x 224 x 510 mm

  • Motherboard Support: ITX, Micro ATX, ATX, SSI CEB, E-ATX (up to 12" x 14.1")

  • Drive Bays: 2x 2.5"/3.5" combo, 2x 2.5"

  • Expansion Slots: 7

  • Pre-installed Fans: 2x 200mm ARGB (front), 1x 120mm ARGB (rear), 1x 120mm GPU fan (top)

  • Fan Support: Front/Top up to 3x 120mm or 2x 200mm, Rear 1x 120mm

  • Radiator Support: Front/Top up to 360mm, Rear 120mm

  • Clearance: CPU Cooler 167mm, GPU 410mm, PSU 180mm

  • I/O Ports: 2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 Type-C, Audio Jack, Reset/ARGB button

  • Special Features: Rotatable GPU fan, ARGB hub, tool-less panels, high airflow mesh front panel


CASE - COOLER MASTER HAF500 White Edition High Airflow ATX Mid-Tower with Mesh Front Panel, Dual 200mm ARGB Lighting Fans, Rotatable GPU Fan, USB 3.2 Gen 2 Type C and Tempered Glass

Cooler Master’s classic HAF series is making a return with HAF 500. Built for high airflow and peak performance, the HAF 500 boasts iconic 200mm large intake ARGB fans, ensuring unparalleled intake and cooling efficiency. The chassis features a dedicated GPU fan, adjustable to various GPU lengths. Ample clearance for dual 360mm radiators on the top and front panel accommodates the most advanced water cooling setups.
Tool-less side panels and a removable top panel facilitate simplified, hassle-free component installation without the need to struggle with small spaces.

Materials

  • Outlook: Steel, Mesh, Plastic

  • Side Panel: Tempered Glass, Steel

Dimensions (L x W x H)
516 x 224 x 510mm (including protrusions)

Motherboard Support
ITX, Micro ATX, ATX, SSI CEB, E-ATX*
(*up to 12" x 14.1", may impact cable management and case features, remove cable cover and GPU fan bracket features)

Expansion Slots
7

Drive Bays

  • 5.25" Drive Bays: N/A

  • 2.5" / 3.5" Drive Bays (Combo): 2

  • 2.5" Drive Bays: 2

I/O Panel

  • 2x USB 3.2 Gen 1 (formerly USB 3.0)

  • 1x USB 3.2 Gen 2 Type-C

  • 1x single Audio Jack

  • 1x Reset/ARGB button

ARGB Controller
ARGB Hub

Pre-installed Fans

  • Front: 2x 200mm ARGB Fan

  • Rear: 1x 120mm SickleFlow PWM ARGB

  • Top on HDD cage: 1x 120mm SickleFlow PWM (GPU Fan)

Fan Support

  • Top: 3x 120mm, 2x 140mm, 2x 200mm

  • Front: 3x 120mm, 2x 140mm, 2x 200mm (*200mm Mounting Hole Spacing 154 x 154 with up to 30mm thickness)

  • Rear: 1x 120mm

  • Top on HDD cage: 1x 120mm

Radiator Support

  • Top: 120mm, 140mm, 240mm, 280mm, 360mm

  • Front: 120mm, 140mm, 200mm, 240mm, 280mm, 360mm

  • Rear: 120mm

Clearance

  • CPU Cooler: 167mm / 6.5"

  • PSU: 180mm / 7.1"

  • GFX: 410mm / 16.1"

Cable Routing
Behind Motherboard Tray: 30mm

Dust Filters
Top, Bottom

Power Supply Support
Bottom Mount, ATX

Series
HAF Series

Size
Mid Tower

CategoryDesktop
SubcategoryComputer Case
BrandCOOLER MASTER
ModelHAF500
