ASUS PRIME B760M-A D4-CSM mATX motherboard Intel LGA1700 up to 128GB DDR4 PCIe 4.0 2.5Gb Ethernet 4K HDMI DP Aura Sync RGB and 7.1 HD Audio

reviews | Write a review

5650 LE

Availability: In Stock

shipped by (sff4$vjs2hf5kg)

Point: 10

Brand : ASUS

Model : PRIME B760M-A D4-CSM

Seller : sff4$vjs2hf5kg

Viewed : 10281 items

ASUS PRIME B760M-A D4-CSM (mATX, LGA1700)

Supports Intel 13th & 12th Gen CPUs

4x DDR4 up to 128GB / 5333 MHz (OC)

2x M.2 PCIe 4.0 + 4x SATA

1x PCIe 4.0 x16

Realtek 2.5Gb LAN

2x HDMI + 1x DisplayPort (4K@60Hz)

USB-C + USB 3.2 Gen 2

Aura Sync RGB support

7.1 HD Audio

Seller note

010084167000099

Fast delivery
2-5 Days
Online Support
Chat and Phone
order protection
secured information
promotion gift
special offers!
money back
return over 14 days

ASUS PRIME B760M-A D4-CSM Motherboard
Socket: LGA 1700
Form Factor: mATX (24.4 cm x 24.4 cm)

CPU Support

Supports Intel® 13th & 12th Gen Core™, Pentium® Gold, and Celeron® processors
Intel® Turbo Boost Technology 2.0 and 3.0 (depending on CPU)

Chipset

Intel® B760

Memory

4 x DDR4 DIMM slots, up to 128GB
Supports DDR4 speeds up to 5333 MHz (OC)
Dual Channel architecture
Intel® XMP support
ASUS OptiMem II for improved stability and overclocking

Graphics Outputs

1 x DisplayPort (up to 4K@60Hz)
2 x HDMI 2.1 ports (up to 4K@60Hz)
(Note: Integrated graphics depend on CPU capabilities)

Expansion Slots

1 x PCIe 4.0 x16 (CPU)
1 x PCIe 4.0 x16 (x4 mode)
1 x PCIe 4.0 x16 (x1 mode)

Storage

2 x M.2 slots (PCIe 4.0 x4)
4 x SATA 6Gb/s ports
Supports RAID 0/1/5/10 (via Intel® Rapid Storage Technology)

Networking

Realtek 2.5Gb Ethernet

USB Ports

Rear I/O:

2 x USB 3.2 Gen 2 Type-A
4 x USB 2.0 Type-A

Internal Headers:

2 x USB 3.2 Gen 1 headers (for 4 ports)
1 x USB 3.2 Gen 1 Type-C connector
2 x USB 2.0 headers (for 4 ports)
1 x USB 2.0 header (for 1 port)

Audio

Realtek 7.1 Surround Sound HD Audio CODEC
Audio shielding, premium capacitors, separate PCB layers
Supports 24-bit/192kHz playback
(Note: Front panel HD audio required for 7.1 output)

Rear I/O Ports

2 x USB 3.2 Gen 2 Type-A
4 x USB 2.0 Type-A
1 x DisplayPort
2 x HDMI ports
1 x Realtek 2.5Gb Ethernet
3 x Audio jacks
1 x PS/2 keyboard/mouse combo port

Internal Connectors

1 x 24-pin ATX Power
1 x 8-pin 12V Power
1 x CPU Fan header
1 x CPU OPT Fan header
2 x Chassis Fan headers
2 x M.2 slots
4 x SATA ports
3 x Addressable Gen 2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x COM Port header
1 x LPT header
1 x S/PDIF Out header
1 x Front Panel Audio header
1 x SPI TPM header (14-1 pin)
1 x 20-3 pin System Panel header with chassis intrusion support

Special Features

ASUS 5X Protection III: DIGI+ VRM, LANGuard, Overvoltage Protection, SafeSlot Core+, Stainless-Steel Back I/O
Q-Design: Q-DIMM, Q-LED Core, Q-Slot
M.2 and VRM heatsinks
ASUS EZ DIY: ProCool connectors
Aura Sync RGB support

Software

Armoury Crate: Aura Creator, Aura Sync, Fan Xpert 2+, Power Saving
AI Suite 3: DIGI+ VRM, PC Cleaner
ASUS CPU-Z
Norton 60-day trial
WinRAR

BIOS

128 Mb Flash ROM, UEFI AMI BIOS
ASUS CrashFree BIOS 3
ASUS EZ Flash 3
UEFI BIOS EZ Mode

Manageability

Supports WOL by PME, PXE

Accessories

2 x SATA 6Gb/s cables
1 x I/O Shield
1 x M.2 Rubber Package
1 x Screw package for M.2 SSD
1 x ACC Express Activation Key Card
1 x User Manual

Operating System

Windows® 10 & 11 64-bit
