Intel Core i7-14700 14th Gen 20 cores 8P 12E 28 threads up to 5.4GHz 33MB cache 65W TDP Intel UHD 770 DDR5 DDR4 support

reviews | Write a review

18000 LE

Availability: In Stock

shipped by (sigma)

Point: 35

Brand : Intel

Model : BX8071514700

Seller : sigma

Viewed : 4841 items

Intel® Core™ i7-14700 (14th Gen) - Key Specs

Cores/Threads: 20 cores (8P + 12E) / 28 threads

Max Turbo Frequency: 5.4 GHz

Base Power / Max Turbo Power: 65W / 219W

Cache: 33MB Smart Cache

Integrated GPU: Intel® UHD Graphics 770

Supported RAM: DDR5 up to 5600 MT/s, DDR4 up to 3200 MT/s

Max Memory: 192 GB – Dual Channel

PCIe Support: Gen 5.0 & 4.0 (up to 20 lanes)

Socket: LGA1700

Launch: Q1 2024

Seller note

005050228000033

Fast delivery
2-5 Days
Online Support
Chat and Phone
order protection
secured information
promotion gift
special offers!
money back
return over 14 days

Intel® Core™ i7-14700 Processor
Product Code: BX8071514700
Launch Date: Q1 2024
Codename: Raptor Lake (14th Gen)
Socket: LGA1700

CPU Specifications:

Total Cores: 20 (8 Performance-cores + 12 Efficient-cores)
Total Threads: 28
Base Frequency:
- P-Cores: 2.1 GHz
- E-Cores: 1.5 GHz
Max Turbo Frequency: 5.4 GHz
P-Core Max Turbo: 5.3 GHz
E-Core Max Turbo: 4.2 GHz
Intel® Turbo Boost Max 3.0: 5.4 GHz
Cache:
- Intel® Smart Cache: 33 MB
- L2 Cache: 28 MB
Processor Base Power: 65W
Maximum Turbo Power: 219W

Memory Support:

Max Memory Size: 192 GB
Memory Types:
- DDR5 up to 5600 MT/s
- DDR4 up to 3200 MT/s
Max Memory Channels: 2
Max Memory Bandwidth: 89.6 GB/s
ECC Memory Support: Yes

Integrated Graphics:

Graphics: Intel® UHD Graphics 770
Base Frequency: 300 MHz
Max Dynamic Frequency: 1.6 GHz
Execution Units: 32
Max Resolutions:
- HDMI: 4096x2160 @ 60Hz
- DP: 7680x4320 @ 60Hz
- eDP: 5120x3200 @ 120Hz
API Support:
- DirectX 12
- OpenGL 4.5
- OpenCL 3.0
Displays Supported: Up to 4

Expansion Options:

DMI: 4.0 (8 lanes)
PCI Express: Gen 5.0 & 4.0
Configurations: Up to 1x16+4 or 2x8+4
Total PCIe Lanes: 20

Package Details:

Package Size: 45.0 mm x 37.5 mm
Thermal Solution Spec: PCG 2020C
Tjunction (Max Temperature): 100°C

Advanced Technologies:

Intel® Hyper-Threading Technology
Intel® Turbo Boost Technology 2.0 & 3.0
Intel® Thread Director
Intel® Deep Learning Boost
Intel® Speed Shift Technology
Intel® Gaussian & Neural Accelerator 3.0
Intel® Volume Management Device (VMD)
Intel® Virtualization Technologies (VT-x, VT-d, VT-rp, EPT)
Intel® Control-Flow Enforcement Technology
Intel® AES-NI, Secure Key, OS Guard
Intel® Trusted Execution Technology
Intel® Boot Guard
Intel® Total Memory Encryption – Multi-Key
Intel® Active Management Technology (AMT)
Intel® vPro® Platform (Enterprise & Essentials)
