AORUS ELITE P1000W 80+ Platinum Modular PCIe 5.0 ICE (rev. 1.0) | 8999 EGP

AORUS ELITE P1000W 80 Platinum Modular PCIe 5.0 ICE rev. 1.0

8999 LE
Availability: In Stock only 5 item left
shipped by (sigma)
Point: 75

Brand : Gigabyte brand

Model : P1000W

Seller : sigma

Viewed : 107 items

Key Features of the PSU

  • Compatibility:
    • ATX 3.0 and PCIe Gen 5.0 ready (compatible with ATX 3.1)
  • Efficiency Rating: 80 PLUS Platinum certified for high energy efficiency
  • Capacitors: 100% Japanese capacitors for improved reliability and performance
  • Cooling System:
    • 120mm smart Fluid Dynamic Bearing (FDB) fan for optimal cooling and low noise
  • Design:
    • Compact design for space-saving installation
    • Fully modular design for easy cable management and customization
  • Power Distribution:
    • Powerful single +12V rail for stable power delivery
  • Protection Features:
    • OVP (Over Voltage Protection)
    • OPP (Over Power Protection)
    • SCP (Short Circuit Protection)
    • UVP (Under Voltage Protection)
    • OCP (Over Current Protection)
    • OTP (Over Temperature Protection)




GP-AE1000PM PG5 ICE Specifications

  • Model: GP-AE1000PM PG5 ICE
  • Type: Intel Form Factor ATX 12V v3.0 (compatible with ATX 3.1)
  • PFC: Active PFC (>0.9 typical)
  • Input Voltage: 100-240 Vac (full range)
  • Input Current: 15-6.5A
  • Input Frequency: 60-50 Hz
  • Output Capacity: 1000W
  • Dimensions: 150 x 140 x 86 mm
  • Fan Type: 120mm Fluid Dynamic Bearing (FDB) Fan
  • 80 PLUS Certification: Platinum
  • Efficiency: 92% at typical load
  • MTBF: >100,000 hours (Mean Time Between Failures)
  • Protection Features: OVP (Over Voltage Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OTP (Over Temperature Protection)
  • Power Good Signal: 100-150 ms
  • Hold Up Time: >16 ms

Cable Specifications

  • Cable Type: Flat, All white
  • Connectors:
    • ATX/MB 20+4 Pin: 1 x 650 mm
    • CPU/EPS 4+4 Pin: 2 x 700 mm
    • PCI-e 16 Pin: 1 x 700 mm
    • PCI-e 6+2 Pin: 6 x (2 x 650 mm + 150 mm, 2 x 750 mm)
    • SATA: 8 x (600 mm + 150 mm + 150 mm + 150 mm, 2)
    • 4 Pin Peripheral: 4 x (500 mm + 150 mm + 150 mm + 150 mm, 1)






CategoryDesktop
SubcategoryPower Supply
BrandGigabyte
ModelP1000W
