GIGABYTE Z890 AORUS ELITE WIFI7 Motherboard - Supports Intel Core Ultra (Series 2) CPUs, 16+1+2 phases VRM, up to 8800MHz DDR5 (OC), 1xPCIe 5.0 + 3xPCIe 4.0, Wi-Fi 7, 2.5GbE LAN, Thunderbolt 4 | 16600 EGP

GIGABYTE Z890 AORUS ELITE WIFI7 Motherboard - Supports Intel Core Ultra Series 2 CPUs 16 1 2 phases VRM up to 8800MHz DDR5 OC 1xPCIe 5.0 3xPCIe 4.0 Wi-Fi 7 2.5GbE LAN Thunderbolt 4

16600 LE
Availability: In Stock only 2 item left
shipped by (sigma)
Point: 50

Brand : Gigabyte brand

Model : Z890

Seller : sigma

Viewed : 309 items

GIGABYTE Z890 AORUS ELITE

  • CPU: LGA1851 socket, supports Intel® Core™ Ultra processors.
  • Chipset: Intel® Z890 Express.
  • Memory: DDR5, up to 256GB (64GB per DIMM), 9200MT/s (OC).
  • Graphics: Thunderbolt™ 4 (5120x2880@60Hz), HDMI, and DisplayPort.
  • Storage: 4x M.2 (PCIe 5.0/4.0, SATA), 4x SATA 6Gb/s.
  • Network: 2.5GbE LAN, Wi-Fi 7, Bluetooth 5.4.
  • USB: Thunderbolt 4, USB 3.2 Gen 2, USB 3.2 Gen 1, USB 2.0.
  • Audio: Realtek® ALC1220, 7.1-channel, S/PDIF Out.
  • Expansion: PCIe 5.0 x16, 2x PCIe 4.0 x4.
  • Cooling: Multiple fan/pump headers, ARGB/RGB headers.
  • Form Factor: ATX (30.5cm x 24.4cm).

GIGABYTE Z890 AORUS ELITE

CPU

  • Socket: LGA1851, supporting Intel® Core™ Ultra processors.
  • Chipset: Intel® Z890 Express Chipset.

Memory

  • Type: DDR5 (up to 9200MT/s with overclocking).
  • Capacity: 4 DIMM slots, up to 256GB total (64GB per module).
  • Features: Dual-channel, ECC (non-ECC mode), XMP support.

Graphics

  • Integrated Intel® HD Graphics (CPU-dependent).
  • Ports:
    • Thunderbolt™ 4 (DisplayPort, max res: 5120x2880@60Hz).
    • HDMI (1920x1080@30Hz).
    • DisplayPort (4096x2304@60Hz).
  • Triple-display support.

Audio

  • Realtek® ALC1220 CODEC, 7.1-channel, S/PDIF Out.

Networking

  • LAN: Realtek® 2.5GbE LAN.
  • Wi-Fi: MediaTek/Realtek Wi-Fi 7, Bluetooth 5.4 (PCB-specific).
  • Windows 11 SV3 required for full Wi-Fi 7 features.

Expansion Slots

  • PCIe:
    • 1x PCIe 5.0 x16 for GPU/NVMe SSD.
    • 2x PCIe 4.0 x4.

Storage

  • M.2 Slots: 4x M.2 (PCIe 5.0/4.0, SATA support).
  • SATA Ports: 4x SATA 6Gb/s.
  • RAID: Supports RAID 0, 1, 5, 10 (NVMe & SATA).

USB Ports

  • Thunderbolt 4: 1x (40Gbps).
  • USB 3.2 Gen 2: 3x (2 rear, 1 internal Type-C®).
  • USB 3.2 Gen 1: 5x (3 rear, 2 internal).
  • USB 2.0: 8x (4 rear, 4 internal).

Power Connectors

  • 24-pin ATX, 2x 8-pin ATX 12V.

Cooling & RGB

  • Multiple fan/water pump headers.
  • 3x ARGB Gen2 headers, 1x RGB header.

Special Features

  • Q-Flash Plus, Smart Backup, GIGABYTE Control Center.

Form Factor

  • ATX (30.5cm x 24.4cm).
