Lenovo IdeaPad Slim 5 16IMH9 83DC003UED
Model Configurations
PERFORMANCE
Processor:
Intel® Core™ Ultra 7 155H, 16C (6P + 8E + 2LPE) / 22T, Max Turbo up to 4.8GHz, 24MB
NPU:
Integrated Intel® AI Boost, up to 11 TOPS
Graphics:
Integrated Intel® Arc™ Graphics
Chipset:
Intel® SoC Platform
Memory:
16GB Soldered LPDDR5x-7467
Memory Slots:
Memory soldered to systemboard, no slots, dual-channel
Max Memory:
16GB soldered memory, not upgradable
Storage:
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Support:
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB
Storage Slot:
Two M.2 slots
• One M.2 2242 PCIe® 4.0 x4 slot
• One M.2 2280 PCIe 4.0 x4 slot
Card Reader:
microSD Card Reader
Optical:
None
Audio Chip:
High Definition (HD) Audio
Speakers:
Stereo speakers, 2W x2, optimized with Dolby Audio™
Camera:
FHD 1080p + IR with Privacy Shutter, ToF Sensor
Microphone:
2x, Array
Battery:
57Wh
Power Adapter:
65W USB-C® (3-pin)
DESIGN
Display:
16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, 60Hz
Touchscreen:
None
Keyboard:
Backlit, Arabic
Touchpad:
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Case Color:
Cloud Grey
Surface Treatment:
Aluminium Stamping (Anodized with Sandblasting)
Case Material:
Aluminium (Top), Aluminium (Bottom)
Pen:
Pen Not Supported
Dimensions (WxDxH):
356 x 251 x 16.9 mm (14.02 x 9.88 x 0.67 inches)
Weight:
Starting at 1.82 kg (4.01 lbs)
SOFTWARE
Operating System:
Windows® 11 Home Single Language, Arabic / English
Bundled Software:
Office Trial
CONNECTIVITY
WLAN + Bluetooth:
Wi-Fi® 6E, 802.11ax 2x2 + BT5.2
WWAN:
Non-WWAN
Ethernet:
No Onboard Ethernet
Standard Ports:
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
2x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with USB PD 3.0 and DisplayPort™ 1.4
1x HDMI® 1.4b
1x Headphone / microphone combo jack (3.5mm)
1x microSD card reader
Monitor Cable:
None
SECURITY & PRIVACY
Security Chip:
Firmware TPM 2.0 Enabled
Fingerprint Reader:
Touch Style, on Palm Rest
Other Security:
Camera privacy shutter
IR camera for Windows® Hello (facial recognition)
SERVICE
Base Warranty:
1-year, Courier or Carry-in
Included Upgrade:
2Y Courier/Carry-in upgrade from 1Y Courier/Carry-in
ACCESSORIES
Bundled Accessories:
None
CERTIFICATIONS
Green Certifications:
ENERGY STAR® 8.0
ErP Lot 6/26
RoHS compliant
Other Certifications:
TÜV Rheinland® Low Blue Light (Software Solution)
TÜV Rheinland® Flicker Free
Mil-Spec Test:
MIL-STD-810H military test passed (21 test items)
