NZXT H510 Elite CA-H510E-B1 Premium Mid-Tower ATX Gaming Case 2 FANS RGB 140MM-1 FAN 120MM- 1FAN 140MM/ BLACK | 3099 EGP

NZXT H510 Elite CA-H510E-B1 Premium Mid-Tower ATX Gaming Case 2 FANS RGB 140MM-1 FAN 120MM- 1FAN 140MM BLACK

3099 LE
shipped by (sigma)
Point: 100

Brand : NZXT brand

Model : CA-H510E-B1

Seller : sigma

Viewed : 5303 items

This compact mid-tower is ideal for highlighting RBG-focused builds with a front tempered glass panel that showcases included Aer 2 RGB fans along with the easy-to-build-in features of the H510.
Two tempered glass panels for showcasing stunning RGB builds.
Two Aer RGB 2 fans and one RGB LED are included
Removable radiator mounting bracket and simple-to-use SSD trays
Patented cable management system
Smart Device 2 with two RGB lighting channels and three fan channels that support 0dB modes for voltage-regulated or PWM fans
USB 3.1 Gen 2-compatible USB-C connector
Iconic cable management bar

Key Specs

Motherboard Support

Mini-ITX, MicroATX, ATX

Enclosure Type

Compact Mid-Tower

Case Material

SGCC Steel, Tempered Glass

Dimensions

Height

460mm / 18.11 inches

Width

210mm / 8.27 inches

Depth

428mm / 16.85 inches

Weight

7.5 kg / 16.53 lb

Compatibility & Clearance

Max CPU Cooler Clearance

165mm

Max GPU Clearance

338 - 368mm

Front Fan & Radiator Clearance

60mm

Vertical GPU Clearance

50.8mm

Cable Management

19 - 23mm

Front I/O Ports

USB 3.2 Gen 2 Type-A

1

USB 3.2 Gen 1 Type-C

1

Headset Audio Jack

1

Smart Device

Fan Channels

3 (10W max per channel)

NZXT RGB Connector

2 (Support up to 40 LEDs)

Expansion Slots

Standard

7

Vertical

2

Drive Bays

2.5"

2 + 1

3.5"

2 + 1

Fan Support

Front

2 x 120mm / 2 x 140mm

Top

1 x 120mm / 1 x 140mm

Rear

1 x 120mm

Filters

All air intakes

Radiator Support

Front

280mm

Top

-

Rear

120mm

Fan Specs

Model

Aer RGB 2 140mm

Speed

500 - 1,500 ± 300RPM

Airflow

30.39 - 91.19 CFM

Static Pressure

0.17 - 1.52 mm-H₂O

Noise

22 - 33 dBA

Fan Connector

4-pin PWM

Fan Specs

Model

Aer P 140mm (Case Version)

Speed

1,000 ± 200RPM

Airflow

68.95 CFM

Noise

28 dBA

Fan Connector

3-pin

Fan Specs

Model

Aer P 120mm (Case Version)

Speed

1,200 ± 200RPM

Airflow

50.42 CFM

Noise

28 dBA

Fan Connector

3-pin

CategoryDesktop
SubcategoryComputer Case
BrandNZXT
ModelCA-H510E-B1
TYPEATX Mid Tower
Case and PSU BundleNO POWER SUPPLY
FANS3 FAN
COLORSBLACK
