APNX V1 Dual-Chamber ATX Mid-Tower Airflow PC Case, Panoramic Glass Panels, 10 Fan Slots, 360mm Radiator Support, Front Angular Intake 16cmx2 Fan Bracket, GPU Mount, Cable Management, Type-C, Black APCM-VI01003.11 | 0 EGP

APNX V1 Dual-Chamber ATX Mid-Tower Airflow PC Case Panoramic Glass Panels 10 Fan Slots 360mm Radiator Support Front Angular Intake 16cmx2 Fan Bracket GPU Mount Cable Management Type-C Black APCM-VI01003.11

0 LE
shipped by (sigma)
Point: 50

Brand : APNX brand

Seller : sigma

Viewed : 62 items

APNX V1 Dual-Chamber ATX Mid-Tower Airflow PC Case

  • Compatibility: ATX, Micro-ATX, Mini-ITX
  • Dimensions: 290 x 485.5 x 500 mm (W x H x D)
  • GPU Clearance: Up to 395 mm
  • CPU Cooler Clearance: Up to 170 mm
  • Cooling Support:
    • Up to 10 Fans (Front, Top, Bottom, Rear)
    • Supports 360 mm Radiators (Front, Top, Bottom)
  • Drive Bays: 2 x 3.5” / 6 x 2.5”
  • Expansion Slots: 7
  • I/O Ports: USB 3.2 Gen 2×2 Type-C, 2 x USB 3.2 Gen 1, Audio & Mic
  • Cable Management: 90 mm Depth
  • PSU Support: ATX (up to 220 mm)

APNX V1 Dual-Chamber ATX Mid-Tower Airflow PC Case

Model: APCM-VI01003.11
Color Options: Black, White, Black/White

Materials:

  • Body: SGCC
  • Front Panel: ABS
  • Steel Thickness: 0.8mm

Motherboard Compatibility:

  • ATX / Micro-ATX / Mini-ITX

Dimensions:

  • Internal: 290 x 460 x 480 mm (W x H x D)
  • Overall: 290 x 485.5 x 500 mm (W x H x D)

Drive Bays:

  • 3.5” Drive Bays: Up to 2 (2 x 3.5”/2.5″)
  • 2.5” Drive Bays: Up to 6 (4 x 2.5” + 2 x 2.5″/3.5”)

Expansion Slots:

  • 7 Slots

Clearance:

  • GPU: Up to 395 mm (without front-right radiator)
  • CPU Cooler: Up to 170 mm

Air Cooling Support:

  • Front-Right: 3 x 120 mm / 2 x 140 mm / 2 x 160 mm (Max)
  • Top: 3 x 120 mm / 2 x 140 mm (Max)
  • Bottom: 3 x 120 mm or 2 x 140 mm (Max)
  • Rear: 1 x 120 mm (Max)

Liquid Cooling Support:

  • Front-Right: 120 / 140 / 240 / 280 / 360 mm Radiator (Optional)
  • Top: 120 / 140 / 240 / 280 / 360 mm Radiator (Optional)
  • Bottom: 120 / 140 / 240 / 280 / 360 mm Radiator (Optional)
    • Note: 140/280 mm radiators fit when the motherboard is in the upper position. Bottom-mounted liquid cooling is not recommended.
  • Rear: 120 mm Radiator (Optional)

Dust Filters:

  • Top (Built-in)
  • Front-Right (Removable)
  • Side (Removable)
  • Bottom (Removable)

I/O Ports:

  • 1 x USB 3.2 Gen 2×2 Type-C
  • 2 x USB 3.2 Gen 1 Type-A
  • Audio & Microphone Jacks

Cable Management:

  • Depth: 90 mm

Power Supply:

  • Supports ATX PSU (up to 220 mm with cables) – Optional
CategoryDesktop
SubcategoryComputer Case
BrandAPNX
ModelAPCM-VI01003.11
