APNX V1 Dual-Chamber ATX Mid-Tower With 4x APNX-FP1-120 ARGB FAN PC Case Panoramic Glass Panels 10 Fan Slots 360mm Radiator Support Front Angular Intake 16cmx2 Fan Bracket GPU Mount Cable Management Type-C Black | 7300 EGP

APNX V1 Dual-Chamber ATX Mid-Tower With 4x APNX-FP1-120 ARGB FAN PC Case Panoramic Glass Panels 10 Fan Slots 360mm Radiator Support Front Angular Intake 16cmx2 Fan Bracket GPU Mount Cable Management Type-C Black

7300 LE
Availability: In Stock
shipped by (sigma)
Point: 50

Brand : APNX brand

Seller : sigma

Viewed : 837 items

APNX V1 Dual-Chamber ATX Mid-Tower PC Case

  • Model: APCM-VI01003.11
  • Colors: Black, White, Black/White
  • Material: SGCC Steel (0.8mm), ABS Front Panel
  • Motherboard Support: ATX / Micro-ATX / Mini-ITX
  • Dimensions: 290 x 485.5 x 500 mm (W x H x D)
  • Drive Bays: 2 x 3.5”/2.5” + 4 x 2.5” + 2 x 2.5”/3.5”
  • Expansion Slots: 7
  • GPU Clearance: Up to 395 mm (without front-right radiator)
  • CPU Cooler Clearance: Up to 170 mm
  • Cooling Support:
    • Air: Up to 10 fans (Front, Top, Bottom, Rear)
    • Liquid: Up to 360 mm radiators (Front, Top, Bottom)
  • Dust Filters: Top (built-in), Front-Right, Side, Bottom (removable)
  • I/O Ports: 1 x USB-C 3.2 Gen 2×2, 2 x USB-A 3.2 Gen 1, Audio/Mic
  • Cable Management Depth: 90 mm
  • PSU Support: ATX (up to 220 mm, optional)

APNX FP1-120 ARGB Fan

  • Size: 120mm
  • Speed: 500–1600 RPM
  • Airflow: 74.6 CFM
  • Noise Level: 33.2 dBA
  • Bearing: Hydraulic (MTBF 60,000 hours)
  • Connectors: PWM 4-pin + ARGB 3-pin
  • Features: Shock-absorbing pads, high airflow, ideal for cases & coolers

APNX V1 Dual-Chamber ATX Mid-Tower PC Case

Model: APCM-VI01003.11
Color Options: Black, White, Black/White

Materials:

  • Body: SGCC
  • Front Panel: ABS
  • Steel Thickness: 0.8mm

Motherboard Compatibility:

ATX / Micro-ATX / Mini-ITX

Dimensions:

  • Internal: 290 x 460 x 480 mm (W x H x D)
  • Overall: 290 x 485.5 x 500 mm (W x H x D)

Drive Bays:

  • 3.5” Drive Bays: Up to 2 (2 x 3.5”/2.5″)
  • 2.5” Drive Bays: Up to 6 (4 x 2.5” + 2 x 2.5″/3.5”)

Expansion Slots:

7 Slots

Clearance:

  • GPU: Up to 395 mm (without front-right radiator)
  • CPU Cooler: Up to 170 mm

Air Cooling Support:

  • Front-Right: 3 x 120 mm / 2 x 140 mm / 2 x 160 mm (Max)
  • Top: 3 x 120 mm / 2 x 140 mm (Max)
  • Bottom: 3 x 120 mm / 2 x 140 mm (Max)
  • Rear: 1 x 120 mm (Max)

Liquid Cooling Support:

  • Front-Right: 120 / 140 / 240 / 280 / 360 mm Radiator (Optional)
  • Top: 120 / 140 / 240 / 280 / 360 mm Radiator (Optional)
  • Bottom: 120 / 140 / 240 / 280 / 360 mm Radiator (Optional)
    • Note: 140/280 mm radiators fit when the motherboard is in the upper position. Bottom-mounted liquid cooling is not recommended.
  • Rear: 120 mm Radiator (Optional)

Dust Filters:

  • Top: Built-in
  • Front-Right: Removable
  • Side: Removable
  • Bottom: Removable

I/O Ports:

  • 1 x USB 3.2 Gen 2×2 Type-C
  • 2 x USB 3.2 Gen 1 Type-A
  • Audio & Microphone Jacks

Cable Management:

  • Depth: 90 mm

Power Supply:

  • Supports ATX PSU (up to 220 mm with cables) – Optional

APNX FP1-120 Black Performance ARGB Fan

Key Specs:

  • Size: 120mm
  • Speed: 500–1600 RPM
  • Airflow: 74.6 CFM
  • Air Pressure: 2.26 mmH₂O | 1.67 mmH₂O
  • Noise Level: 33.2 dBA
  • Bearing: Hydraulic, MTBF 60,000 hours
  • Connectors: PWM 4-pin + ARGB 3-pin
  • Features: Shock-absorbing pads, high airflow, ideal for cases & coolers
CategoryDesktop
SubcategoryComputer Case
BrandAPNX
ModelAPCM-VI01003.11
