MSI PRO Z790-P WiFi ProSeries Motherboard (Supports 12th/13th/14th Gen Intel Processors, LGA 1700, DDR5, PCIe 5.0, M.2, 2.5Gbps LAN, USB 3.2 Gen2, HDMI/DP, Wi-Fi 6E, Bluetooth 5.3, ATX) | 11249 EGP

MSI PRO Z790-P WiFi ProSeries Motherboard Supports 12th 13th 14th Gen Intel Processors LGA 1700 DDR5 PCIe 5.0 M.2 2.5Gbps LAN USB 3.2 Gen2 HDMI DP Wi-Fi 6E Bluetooth 5.3 ATX

11249 LE
Availability: In Stock
shipped by (sigma)
Point: 30

Brand : MSI brand

Seller : sigma

Viewed : 85 items

  • Socket: LGA 1700
  • Processor Support: 12th, 13th, and 14th Gen Intel processors
  • Memory Support: DDR5 RAM
  • Expansion Slots:
    • PCIe 5.0 support for high-speed graphics and other expansion cards
  • Storage:
    • Multiple M.2 slots for NVMe SSDs
  • Networking:
    • 2.5Gbps LAN for fast wired connections
    • Wi-Fi 6E for improved wireless connectivity
    • Bluetooth 5.3 for wireless peripherals
  • USB Ports: USB 3.2 Gen 2 for high-speed data transfer
  • Video Output: HDMI and DisplayPort for video connectivity
  • Form Factor: ATX




Specifications:

Chipset:

  • Chipset: Intel Z790
  • Socket: LGA 1700
  • CPU Support:
    • Intel® Core™ 14th/13th/12th Gen Processors
    • Intel® Pentium® Gold and Celeron® Processors

Memory:

  • Memory Slots: 4 x DDR5
  • Maximum Memory Capacity: 256GB
  • Memory Support:
    • Overclocking speeds:
      • Up to 7000+ MHz (1DPC 1R)
      • Up to 6600+ MHz (1DPC 2R)
      • Up to 6400+ MHz (2DPC 1R)
      • Up to 5600+ MHz (2DPC 2R)
    • Supports Intel® XMP 3.0 OC
    • Dual-Channel mode and non-ECC, unbuffered memory

Graphics:

  • Onboard Graphics Outputs:
    • 1 x HDMI™ (HDMI 2.1 with HDR, max resolution 4K at 60Hz)
    • 1 x DisplayPort (DP 1.4, max resolution 4K at 60Hz)
  • Note: Graphics specifications may vary based on the CPU used.

Expansion Slots:

  • PCI-E Slots:
    • 3 x PCI-E x16 slots
    • 1 x PCI-E x1 slot
    • Slot specifications:
      • PCI_E1 (PCIe 5.0, x16 from CPU)
      • PCI_E2 (PCIe 3.0, x1 from Chipset)
      • PCI_E3 (PCIe 4.0, x4 from Chipset)
      • PCI_E4 (PCIe 3.0, x1 from Chipset)

Audio:

  • Audio Codec: Realtek® ALC897
  • Audio Channels: 7.1-Channel High Definition Audio

Storage:

  • M.2 Slots:
    • 4 x M.2 slots
      • M.2_1 (From CPU): PCIe 4.0 x4 (supports 22110/2280/2260/2242 devices)
      • M.2_2 (From Chipset): PCIe 4.0 x4 (supports 2280/2260/2242 devices)
      • M.2_3 (From Chipset): PCIe 4.0 x4/SATA (supports 2280/2260/2242 devices)
      • M.2_4 (From Chipset): PCIe 4.0 x4/SATA (supports 2280/2260/2242 devices)
  • SATA Ports: 6 x SATA 6G
  • RAID Support:
    • Supports RAID 0, 1, 5, and 10 for both SATA and M.2 NVMe storage devices

USB Ports:

  • Rear USB:
    • 4 x USB 2.0
    • 2 x USB 5Gbps Type A
    • 1 x USB 10Gbps Type A
    • 1 x USB 20Gbps Type C
  • Front USB:
    • 4 x USB 2.0
    • 4 x USB 5Gbps Type A
    • 1 x USB 10Gbps Type C

Networking:

  • LAN: Intel® 2.5Gbps LAN
  • Wireless LAN & Bluetooth:
    • Intel® Wi-Fi 6E (supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz up to 2.4Gbps)
    • Bluetooth® 5.3

Internal I/O Connectors:

  • Power connectors for ATX and CPU
  • Fan connectors (CPU, Pump, and System)
  • Front Panel connectors
  • Chassis Intrusion header
  • Front Audio header
  • RGB LED connectors
  • TPM pin header (supports TPM 2.0)
  • Multiple USB 2.0 and Type C ports

LED Feature:

  • 4 x EZ Debug LED for troubleshooting



CategoryDesktop
SubcategoryMotherboard
BrandMSI
ModelPRO Z790-P WiFi
