DeepCool CC560 Mid-Tower Case: Supports up to 6 fans and 360mm radiators, fits 370mm GPUs, 163mm CPU coolers, 2× SSDs, 2× HDDs, tempered glass panel, and USB 3.0 | 1699 EGP

DeepCool CC560 Mid-Tower Case Supports up to 6 fans and 360mm radiators fits 370mm GPUs 163mm CPU coolers 2 SSDs 2 HDDs tempered glass panel and USB 3.0

1699 LE
Availability: In Stock
shipped by (sigma)
Point: 25

Brand : DEEPCOOL brand

Seller : sigma

Viewed : 1046 items

DeepCool CC560 Mid-Tower Case – Key Specifications

  • Cooling & Airflow:

    • 4 pre-installed LED fans (3×120mm front, 1×120mm rear)
    • Supports up to 6×120mm or 4×140mm fans
    • Radiator support: Up to 360mm (front), 240mm (top), 120mm (rear)
  • Hardware Compatibility:

    • Max CPU Cooler Height: 163mm
    • Max GPU Length: 370mm
    • Max PSU Length: 170mm
  • Storage:

    • 2× 2.5” SSDs (backplate)
    • 2× 3.5” HDDs (removable drive cage)
  • Design & Features:

    • Full-sized tempered glass side panel
    • Magnetic dust filter (top)
    • Front I/O: USB 3.0 ×1, USB 2.0 ×1, Audio ×1
  • Dimensions & Weight:

    • 416×210×477mm (L×W×H)
    • 5.25Kg


DeepCool CC560 Mid-Tower Case

The DeepCool CC560 Mid-Tower Case delivers excellent value with its spacious component compatibility, full-sized tempered glass window, and four pre-installed LED fans for strong airflow right out of the box.

Optimized Airflow Performance

Designed for efficient cooling, the CC560 features a ventilated front panel and a large mesh top panel, ensuring continuous airflow throughout the chassis.

Pre-Installed Cooling

Equipped with four pre-installed LED fans, the case provides high airflow performance to maintain optimal system temperatures.

Cooling Support

  • Supports AIO liquid coolers with space for up to a 360mm radiator in the front or a 240mm radiator on top.
  • Fan support:
    • Up to 6x 120mm or 4x 140mm case fans.
  • Radiator support:
    • Front: 120mm / 140mm / 240mm / 280mm / 360mm
    • Top: 120mm / 240mm
    • Rear: 120mm

Hardware Compatibility

  • Max CPU Cooler Height: 163mm
  • Max GPU Length: 370mm
  • Max PSU Length: 170mm

Storage Options

  • Supports up to 2x 2.5” SSDs mounted on the backplate.
  • Includes a removable drive cage for 2x 3.5” HDDs under the PSU shroud.

Additional Features

  • Full-sized tempered glass side panel.
  • Magnetic dust filter on the top panel.
  • Front I/O panel with USB 3.0, USB 2.0, and a combo audio jack.

Technical Specifications

  • Product Dimensions: 416×210×477mm (L×W×H)
  • Net Weight: 5.25Kg
  • Materials: ABS + SPCC + Tempered Glass
  • Motherboard Support: Mini-ITX / Micro-ATX / ATX
  • Front I/O Ports: USB 3.0 ×1, USB 2.0 ×1, Audio ×1
  • Drive Bays:
    • 3.5" Drive Bays: 2
    • 2.5" Drive Bays: 2
  • Expansion Slots: 7 Slots
  • Pre-Installed Fans:
    • Front: 3×120mm
    • Rear: 1×120mm
  • Fan Support:
    • Front: 3×120mm / 2×140mm
    • Top: 2×120mm / 2×140mm
    • Rear: 1×120mm
  • Radiator Support:
    • Front: 120mm / 140mm / 240mm / 280mm / 360mm
    • Top: 120mm / 240mm
    • Rear: 120mm
  • Power Supply Type: ATX PS2 (Maximum length: 170mm)
  • EAN Code: 6933412714880
  • PN Code: R-CC560-BKGAA4-G-1
CategoryDesktop
SubcategoryComputer Case
BrandDEEPCOOL
ModelR-CC560-BKGAA4-G-1
