DeepCool PF500 – 80 PLUS 230V EU certified 500W, 120mm hydraulic bearing fan, flat black cables, OPP/OVP/SCP protection, and 100,000-hour MTBF | 1300 EGP

DeepCool PF500 80 PLUS 230V EU certified 500W 120mm hydraulic bearing fan flat black cables OPP OVP SCP protection and 100 000-hour MTBF

1300 LE
shipped by (sigma)
Point: 5

Brand : DEEPCOOL brand

Seller : sigma

Viewed : 500 items

DeepCool PF500 80 PLUS Standard Power Supply

  • 80 PLUS 230V EU Certified – 85% efficiency at 50% load.
  • 120mm Hydraulic Bearing Fan – Low noise, improved lifespan.
  • Flat Black Cables – Easy cable management.
  • Protections: OPP, OVP, SCP.
  • Connectors:
    • 24 (20+4) Pin ×1
    • 8 (4+4) Pin ×1
    • PCI-E (6+2) Pin ×2
    • SATA ×3 + 4-Pin Peripheral ×1 ×2
  • Dimensions: 150 × 140 × 86mm
  • MTBF: 100,000 Hours





DeepCool PF500 80 PLUS Standard Power Supply

The DeepCool PF500 is a reliable and affordable 80 PLUS Standard power supply unit designed to deliver stable and safe power performance.

Key Features

  • 80 PLUS 230V EU Standard Certification
    Ensures 85% efficiency at 50% load, reducing energy waste and keeping temperatures lower for better cost savings.

  • 120mm Silent Hydraulic Bearing Fan
    Optimized for low-noise performance, improving lifespan while reducing friction and vibration.

  • Flat Black Cables
    Flexible and space-saving design for easier cable management.

  • Comprehensive Protection
    Equipped with Over Power Protection (OPP), Over Voltage Protection (OVP), and Short Circuit Protection (SCP) for enhanced safety.

Specifications

  • Type: ATX12V V2.4
  • Dimensions: 150 × 140 × 86mm (W x L x H)
  • 80 PLUS Certification: 230V EU White
  • Fan Size: 120mm
  • Fan Bearing: Hypro Bearing
  • Topology: Active PFC + Double Tube Forward
  • Capacitors: Taiwan Bulk Capacitor
  • Power Good Signal: 100-500ms
  • Hold Up Time: ≥16ms (75% Load)
  • Efficiency: ≥85% at 50% Load
  • Protections: OPP / OVP / SCP
  • Operating Temperature: 0-40°C
  • Regulatory Compliance: CB, CCC, CE, UKCA, EAC, RCM, BIS
  • ErP Compliance: ErP 2010
  • MTBF: 100,000 Hours

Connectors

  • Main Power Connector: 24 (20+4) Pin ×1
  • EPS 12V Connector: 8 (4+4) Pin ×1
  • PCI-E (6+2) Pin: ×2
  • SATA ×3 + 4-Pin Peripheral ×1: ×2



CategoryDesktop
SubcategoryPower Supply
BrandDEEPCOOL
ModelR-PF500D-HA0B-EU
